Feature Introduction:
ABS K5 is an easy-to-print ABS material, which improves typical ABS materials’ warping and cracking. With ABS materials’ high mechanical performance, it is a modified version with a less pungent smell, lower shrinkage, and lower printing temperatures.
Basic Physical Properties:
ABS K5 | Printed copy (horizontal printing of sample, 100% linear filling) | Injection molded parts | Test standards |
Density (g/cm3) | 1.05 | ISO 1183 | |
Melt flow rate (MFR) 1 | 30-35 | ISO 1133 | |
Heat deflection temperature(HDT)2 | 85 | ISO 75 | |
Vicat softening temperature(VST)3 | 95 | ISO 306 | |
Tensile strength (MPa) | 40-42 | ISO 527 | |
Elongation at break(%) | 10-12 | ||
Maximum force(Mpa) | 75-80 | ISO 178 | |
Flexural modulus(Mpa) | 2600-2800 | ||
Impact strength(KJ/m2) | 38-42 | ISO 179 | |
Notch impact strength1(KJ/m2) | 18-22 |
*1. Test condition: temperature (T)=220 ℃; Mass (m)=10kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
