Feature Introduction:
ABS K5 is an ABS consumable that is easy to print. This consumable improves the defects of ordinary ABS materials that are easy to warp and crack when printing, retains the original good comprehensive mechanical properties of ABS materials, lower odor, lower shrinkage and lower printing temperature, and makes your printing process more simple, efficient, practical and fun.
Specification And Color:
The product of this brand provides three specifications of wire diameter: 1.75mm, 2.85mm and 3.0mm, and the wire diameter tolerance is ± 0.03mm. The weight of each roll can be 1kg, 3kg, 5kg or 10kg. 39 solid colors and 4 luminous colors are available.
Print Parameter Settings:
Printing temperature: 220-250 ℃, platform temperature: 80-100 ℃, printing speed: 40-80mm/s, cooling fan: OFF.
Basic Physical Properties:
| ABS K5 | Printed copy (horizontal printing of sample, 100% linear filling) | Injection molded parts | Test standards |
| Density (g/cm3) | 1.05 | ISO 1183 | |
| Melt index (g/10min) * 1 | 30-35 | ISO 1133 | |
| Thermal deformation temperature (℃) * 2 | 85 | ISO 75 | |
| Vicat softening temperature (℃) * 3 | 95 | ISO 306 | |
| Tensile strength (MPa) | 41 | ISO 527 | |
| Tensile elongation at break (%) | 11 | ||
| Bending strength (MPa) | 77 | ISO 178 | |
| Bending modulus (MPa) | 2600 | ||
| Notched impact strength (KJ/m2) | 39 | ISO 179 | |
| Notch impact strength (KJ/m2) | 20 | ||
*1. Test condition: temperature (T)=220 ℃; Mass (m)=10kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
Recommended Applications:
ABS K5 is recommended to be applied to models and parts that require certain heat resistance temperature and impact strength. Of course, there is no doubt that this product will print general models.
