Feature Introduction:
PET K7CF is a carbon fiber-reinforced PET material with high stiffness, rigidity, strength, and wear resistance. As an entry-level high-performance FDM filament, it is easy to print without rigorous printing conditions. Compared with PA/CF, PET K7CF is less absorbent and more applicable to high-performance structural parts.
Basic Physical Properties:
PET K7CF | Printed copy (horizontal printing of sample, 100% linear filling) | Injection molded parts | Test standards |
Density (g/cm3) | 1.35-1.4 | ISO 1183 | |
Melt flow rate (MFR) 1 | 6-12 | ISO 1133 | |
Heat deflection temperature(HDT)2 | 102 | ISO 75 | |
Vicat softening temperature(VST)3 | 83 | ISO 306 | |
Tensile strength (MPa) | 50-60 | ISO 527 | |
Elongation at break(%) | 2-4 | ||
Maximum force(Mpa) | 90-100 | ISO 178 | |
Flexural modulus(Mpa) | 5000-6000 | ||
Impact strength(KJ/m2) | 20-30 | ISO 179 | |
Notch impact strength1(KJ/m2) | 6-8 |
*1. Test condition: temperature (T)=270 ℃; Mass (m)=2.16kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
