THE K11™ PEKK

  • TOUGHNESS
  • STRENGTH
  • HEAT RESISTANCE
  • Printability
  • Rigidity
  • Z-axis strength
CHOOSE DIAMETER
  • 1.75mm
CHOOSE WEIGHT
  • 0.25kg
  • 0.5kg
  • 1kg
CHOOSE COLORS
COLOR:
  • Natural

Feature Introduction:

THE K11™ PEKK is a PEKK material with low crystallization speed. Supplied consumables and printed products are generally transparent and amorphous. With its inherent resistance to flame and temperature, and high strength, PEKK K10IAM prints products with high-quality interlayer adhesion, thus it is prone to print parts with higher-strength Z-axis than typical PEEK materials.

Basic Physical Properties:

THE K11™ PEKK

Printed copy (horizontal printing of sample, 100% linear filling)Injection molded partsTest standards
Density (g/cm3)1.28ISO 1183
Melt flow rate (MFR) 16-8ISO 1133
Heat deflection temperature(HDT)2150 ISO 75
Vicat softening temperature(VST)3157.8 ISO 306
Tensile strength (MPa)80-100 ISO 527
Elongation at break(%)4-6
Maximum force(Mpa)140-170 ISO 178
Flexural modulus(Mpa)2900-3300
Impact strength(KJ/m2)50-60 ISO 179
Notch impact strength1(KJ/m2)4-8

*1. Test condition: temperature (T)=380 ℃; Mass (m)=1kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
