THE K11™ PPSU

  • TOUGHNESS
  • STRENGTH
  • HEAT RESISTANCE
  • Printability
  • Rigidity
  • Z-axis strength
CHOOSE DIAMETER
  • 1.75mm
CHOOSE WEIGHT
  • 0.5kg
  • 1kg
CHOOSE COLORS
COLOR:
  • Natural

Feature Introduction:

THE K11™ PPSU is one of the best temperature-resistance thermoplastics with heat deflection temperatures over 200 ℃, without significant changes in mechanical and electrical properties within a wide temperature range. With high toughness and flame retardancy grade up to UL94 V-0, it is able to withstand thousands of sterilization processing of high-temperature steam and ultraviolet rays, thus it is applicable to automotive and electrical industries. It is also bisphenol A-free and applicable to medical and food industries.

Basic Physical Properties:

THE K11™ PPSU

Printed copy (horizontal printing of sample, 100% linear filling)Injection molded partsTest standards
Density (g/cm3)1.29ISO 1183
Melt flow rate (MFR) 130-35ISO 1133
Heat deflection temperature(HDT)2208 ISO 75
Vicat softening temperature(VST)3220 ISO 306
Tensile strength (MPa)50-60 ISO 527
Elongation at break(%)10-12
Maximum force(Mpa)80-85 ISO 178
Flexural modulus(Mpa)1900-2100
Impact strength(KJ/m2)70-90 ISO 179
Notch impact strength1(KJ/m2)15-20

*1. Test condition: temperature (T)=365 ℃; Mass (m)=5kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
