THE K6™ PLA CF10

  • TOUGHNESS
  • STRENGTH
  • HEAT RESISTANCE
  • Printability
  • Rigidity
  • Z-axis strength
CHOOSE DIAMETER
  • 1.75mm
  • 2.85mm
CHOOSE WEIGHT
  • 0.5kg
  • 1kg
CHOOSE COLORS
COLOR:
  • Black

Feature Introduction:

THE K6™ PLA CF10 is a modified PLA composite material with a balance of strength, rigidity, and toughness. As the optimum for introductory composite printing, it can print structural and other functional models in addition to general models.

Basic Physical Properties:

THE K6™ PLA CF10Printed copy (horizontal printing of sample, 100% linear filling)Injection molded partsTest standards
Density (g/cm3)1.22-1.24ISO 1183
Melt flow rate (MFR) 14-6ISO 1133
Heat deflection temperature(HDT)255 ISO 75
Vicat softening temperature(VST)357 ISO 306
Tensile strength (MPa)33-35 ISO 527
Elongation at break(%)8-12
Maximum force(Mpa)90-95 ISO 178
Flexural modulus(Mpa)4000-4500
Impact strength(KJ/m2)24-28 ISO 179
Notch impact strength1(KJ/m2)4-6

*1. Test condition: temperature (T)=190 ℃; Mass (m)=2.16kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
