THE K10™ PPS CF10
THE K10™ PPS CF10 is a high-performance, carbon fiber reinforced polyphenylene sulfide material. Its exceptional strength, rigidity, and heat resistance make it ideal for demanding applications. This material can withstand continuous use at temperatures exceeding 200°C and maintains excellent dimensional stability. Its inherent flame retardancy further enhances its suitability for high-pressure components in sectors such as automotive and aerospace.
Suggested Printing Parameters
| Nozzle temperature | 230 ~ 260℃ |
| Bed temperature | 70 ~ 80℃ |
| Bed modification | PEI frosted board |
| Active cooling fan | 0 ~ 50% |
| Layer height | 0.2mm |
| Shell thickness | ≥ 0.8mm |
| Print speed | ≤ 200mm/s |
Technical Data Sheet (TDS)
| Material Properties | Typical Value | Test Method |
|---|---|---|
| Melt flow rate (MFR)¹ | 10~20g/10min | ISO 1133 |
| Heat deflection temperature (HDT)² | 257℃ | ISO 75 |
| Vicat softening temperature (VST)³ | 271.9℃ | ISO 306 |
| Density | 1.31~1.33g/cm³ | ISO 1183 |
| Odor | Odorless | / |
| Solubility | Insoluble in water | / |
Select a color
Weight options:
: 250g, 500g, 1kg
