THE K11™ PEI 1010
THE K11™ PEI 1010 is a polyetherimide material applicable to 3D printing. It is characterized by multiple properties, including high strength and toughness, heat deflection temperature and Vicat softening temperature up to about 200°C, resistance to gasoline, various hydrocarbon solvents, dilute acids and alkalis, and flame retardancy grade up to UL94 V-0. It is widely applicable to concept modeling, functional prototypes, end-use components.
Suggested Printing Parameters
| Nozzle temperature | 360 ~ 390℃ |
| Bed temperature | 150 ~ 240℃ |
| Chamber temperature | 90 ~ 220℃ |
| Bed modification | High temperature glue |
| Active cooling fan | OFF |
| Layer height | 0.2mm |
| Shell thickness | ≥ 0.8mm |
| Print speed | 30~60mm/s |
Technical Data Sheet (TDS)
| Material Properties | Typical Value | Test Method |
|---|---|---|
| Melt temperature (HDT)² | ~320℃ | ISO 11357 |
| Melt flow rate (MFR)¹ | 35~40g/10min | ISO 1133 |
| Heat deflection temperature (HDT)² | 208℃(before annealing)/ 182℃(after annealing) | ISO 75 |
| Vicat softening temperature (VST)³ | 210℃ | ISO 306 |
| Density | 1.28g/cm³ | ISO 1183 |
| Odor | Odorless | / |
| Solubility | Insoluble in water | / |
Select a color
Weight options:
: 250g, 500g, 1kg
