THE K5™ PLA CF
This is a high-performance filament that combines the strength and stiffness of carbon fiber with the ease of printing PLA. Ideal for creating strong, durable, and lightweight 3D printed parts.
Suggested Printing Parameters
| Nozzle temperature | 210 ~ 250℃ |
| Bed temperature | 35 ~ 55℃ |
| Bed modification | PEI frosted board |
| Active cooling fan | ON,50~100% |
| Layer height | 0.2mm |
| Shell thickness | ≥ 0.8mm |
| Print speed | ≤ 250mm/s |
Technical Data Sheet (TDS)
| Material Properties | Typical Value | Test Method |
|---|---|---|
| Melt temperature | ~160℃ | ISO 11357 |
| Glass transition temperature | ~60℃ | ISO 11357 |
| Melt flow rate (MFR)¹ | 5~10g/10min | ISO 1133 |
| Heat deflection temperature (HDT)² | 60℃ | ISO 75 |
| Vicat softening temperature (VST)³ | 68℃ | ISO 306 |
| Density | 1.21~1.23g/cm³ | ISO 1183 |
| Odor | Odorless | / |
| Solubility | Insoluble in water | / |
Select a color
Weight options:
: 1kg, 3kg, 5kg
