THE K10™ PC

THE K10™ PC is a high heat-resistance PC material for industrial FDM/FFF 3D printers. With mechanical properties comparable to normal PC materials, its softening temperature is increased by more than 30°C, which is close to PEI, but easier to print than PEI.

Technical Data Sheet (TDS)

Material Properties	Typical Value	Test Method
Melt flow rate (MFR)¹	30~35g/10min	ISO 1133
Melt temperature (HDT)²	~280℃	ISO 75
Heat deflection temperature (HDT)²	163℃	ISO 75
Vicat softening temperature (VST)³	176℃	ISO 306
Density	1.18~1.20/cm³	ISO 1183
Odor	Odorless	/
Solubility	Insoluble in water	/

        Suggested Printing Parameters

                Nozzle temperature
                310 ~ 350℃

                Bed temperature
                140 ~ 180℃

                Chamber temperature
                80 ~ 150℃

                Bed modification
                NO & High temperature glue

                Active cooling fan
                OFF

                Layer height
                0.2mm

                Shell thickness
                ≥ 0.8mm

                Print speed
                30-60mm/s

        Settings are based on a 0.4mm nozzle.
