THE K8™ PA CF
THE K8™ PA CF (Nylon) is a high-performance, carbon fiber-reinforced polyamide filament designed for demanding applications. This material offers exceptional strength, stiffness, and heat resistance, making it ideal for creating durable, functional parts. With its excellent printability and low moisture absorption, this filament is easy to use and provides consistent results.
Select a color
Weight options:
: 1kg, 3kg, 5kg
Suggested Printing Parameters
| Nozzle temperature | 270 ~ 310℃ |
| Bed temperature | 90 ~ 110℃ |
| Bed modification | Tape or glue |
| Active cooling fan | 0~50% |
| Layer height | 0.2mm |
| Shell thickness | ≥ 0.8mm |
| Print speed | ≤ 350mm/s |
Technical Data Sheet (TDS)
| Material Properties | Typical Value | Test Method |
|---|---|---|
| Melt flow rate (MFR)¹ | 30~40g/10min | ISO 1133 |
| Heat deflection temperature (HDT)² | 186℃ | ISO 75 |
| Vicat softening temperature (VST)³ | 203℃ | ISO 306 |
| Density | 1.16~1.18g/cm³ | ISO 1183 |
| Odor | Odorless | / |
| Solubility | Insoluble in water | / |
